Key Features:

• Interior LED surface mounted wall light
• Matt white bow shape
• Material: iron & aluminium powder coated white & acrylic
• 12V inbuilt constant current LED driver included
• Driver output voltage: 12-22V
• Driver input current: 0.11A
• Driver output current: 0.3A
• LED chips: 1pc 2835 COB LED
• Power factor: 0.5
• Ambient Temperature: -20 to 50°C
• Not suitable for dimming
• Suitable for 2-way switching
• Suitable for use with PIR & Microwave sensors
• IP rating: IP20
• Back plate: L 120 x W 40 x D 45mm
• Mounting U bracket: 100x20mm, central 10mm cable hole
• Warranty: 2 year replacement warranty

*Must be installed by a licenced electrician (Installation instructions sheet provided in each product box).

Part No: DAVOS
Description: WALL Int S/M Up/Dn 6W BOW Matt Wh 3K 254 Lm
Colour: Fitting Trim: White & Satin Chrome; Housing: Matte White; Mount: Matte White;
Material: Housing: Aluminium; Mount: Metal;
Input Voltage: 220-240V AC
Wattage: 6W
Kelvin: 3000K
Lumens: 480lm
Beam Angle: 120 Degree
Power Factor: 0.5
CRI: >80
Diameter / Width: 160mm
Height: 40mm
Box Size: 24x19x15cm
Box Weight: 1kg

Brochure: DAVOS (634.95 KB)
Technical Spec: DAVOS (66.03 KB)
